Z109REG2-1 | Analog / Universal Converters | SENECA
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | SENECA |
| MPN | Z109REG2-1 |
| Country/Region Of Manufacture | Italy |
High performance universal converter, programmable via MicroUSB/App The Z109REG2 module acquires an universal input signal, converts it to an analog format and send it to an universal isolated output. Specifications: Universal Input: current, thermocouples, thermoresistances, potentiometer, rheostat. Measurement and re-transmission on osolated analog output, with voltage and current output. DIP-switvh for selecting: type of input, START-END, output mode. front panel indicating: power on, off scale or setting error and alarm status. . Relay output, programmable through a PC. 3-point insulation:1500V To see a comparison table of similar products, click here. SpecificationsGENERAL DATA Power supply10..40 Vdc; 19..28 VacPower TransducersActive input @ 2 wires (min 20 Vdc)Power Consumption2,5 W (max) - 1,6 W (24 Vdc, 20 mAIsolation3.750 Vac (power supply / input / output)ProtectionAgainst pulse overvoltages: 400 W /msProtection degreeIP20LED status indicatorsPower Supply - Error - AlarmResponse time35 ms (11 bit)..140 ms (16 bit) 35InterfacesMicro USBAccuracy class0,10%Thermal drift0.01%/KLinearity0,05% / 0.4%SettingDIP switch - Software (EASY SETUP) - App (EASY SETUP)Operating temperature-20..+60°CDimension17,5 x 100 x 112 mmConnessioniScrew removable terminals 2,5 mm2EnclosureNylon 6 with 30% fiber glassMountingGuida DIN 35 mm (IEC/EN 60175)Weight200 gApprovalsCE, ULNormsEN 61000-6-4, EN 61000-6-2, EN 61010-1INPUT DATA Channels1 analogico, 1 strobeTypeVOLTAGE (mV, V): Bipolar from 75 mV to 20 V, resolution 15 bit + sign CURRENT (mA): Bipolar up to 20 mA, resolution 1 µA RTD: Pt100, Pt500, Pt1000, Ni100, KTY81, KTY84, NTC; 3-4 wires measure; scalw: -200..600 °C, resolution 0,1°C THERMOCOUPLE: Type J, K, R, S, T, E, B, N, Resolution 2,5 µV POTENTIOMETER: 500 O ..10 kO RHEOSTAT: 500 O..25 kO STROBE: Alternative to output relayOUTPUT DATA Channels1 analog, 1 relay outputTypeVOLTAGE (V): 4 scales: 0/1..5V, 0/2..10V, Min load resistance: 2 kO CURRENT (mA): 2 scales: 0/4..20 mA, Max load resistance: 600 O RELAY: alternative to strobe input NC / NO in case alarm
